Таблица «Сортамент труб стальных бесшовных холоднодеформированных по ГОСТ 8734-78»:
|
Наружный диаметр, мм |
Толщина стенки, мм |
Масса 1 м труб, кг |
|
6 |
1.6 |
0.174 |
|
1.8 |
0.186 |
|
|
7 |
1.6 |
0.213 |
|
1.8 |
0.231 |
|
|
8 |
1.6 |
0.253 |
|
1.8 |
0.275 |
|
|
9 |
1.6 |
0.292 |
|
1.8 |
0.320 |
|
|
10 |
1.6 |
0.331 |
|
1.8 |
0.364 |
|
|
11 |
1.6 |
0.371 |
|
1.8 |
0.408 |
|
|
12 |
1.6 |
0.410 |
|
1.8 |
0.453 |
|
|
13 |
1.6 |
0.450 |
|
1.8 |
0.497 |
|
|
2.0 |
0.543 |
|
|
14 |
1.6 |
0.489 |
|
1.8 |
0.542 |
|
|
2.0 |
0.592 |
|
|
|
2.2 |
0.640 |
|
15 |
1.6 |
0.529 |
|
1.8 |
0.568 |
|
|
2.0 |
0.641 |
|
|
2.0 |
0.694 |
|
|
2.5 |
0.771 |
|
|
16 |
1.6 |
0.568 |
|
1.8 |
0.630 |
|
|
2.0 |
0.691 |
|
|
2.2 |
0.749 |
|
|
2.5 |
0.832 |
|
|
17 |
1.6 |
0.608 |
|
1.8 |
0.675 |
|
|
2.0 |
0.740 |
|
|
2.2 |
0.803 |
|
|
2.5 |
0.894 |
|
|
2.8 |
0.981 |
|
|
18 |
1.6 |
0.647 |
|
1.8 |
0.719 |
|
|
2.0 |
0.789 |
|
|
2.2 |
0.857 |
|
|
2.5 |
0.956 |
|
|
2.8 |
1.050 |
|
|
3.0 |
1.110 |
|
|
19 |
1.6 |
0.687 |
|
1.8 |
0.764 |
|
|
2.0 |
0.838 |
|
|
2.2 |
0.911 |
|
|
2.5 |
1.017 |
|
|
2.8 |
1.119 |
|
|
3.0 |
1.184 |
|
|
20 |
1.8 |
0.808 |
|
2.0 |
0.888 |
|
|
2.2 |
0.966 |
|
|
2.5 |
1.079 |
|
|
2.8 |
1.188 |
|
|
3.0 |
1.258 |
|
|
3.2 |
1.326 |
|
|
21 |
1.8 |
0.852 |
|
2.0 |
0.937 |
|
|
2.2 |
1.020 |
|
|
2.5 |
1.141 |
|
|
2.8 |
1.257 |
|
|
|
3.0 |
1.332 |
|
3.2 |
1.405 |
|
|
3.5 |
1.511 |
|
|
22 |
1.8 |
0.897 |
|
2.0 |
0.986 |
|
|
2.2 |
1.074 |
|
|
2.5 |
1.202 |
|
|
2.8 |
1.326 |
|
|
3.0 |
1.406 |
|
|
3.2 |
1.484 |
|
|
3.5 |
1.597 |
|
|
23 |
2.0 |
1.036 |
|
2.2 |
1.129 |
|
|
2.5 |
1.264 |
|
|
2.8 |
1.395 |
|
|
3.0 |
1.480 |
|
|
3.2 |
1.563 |
|
|
3.5 |
1.683 |
|
|
24 |
2.0 |
1.085 |
|
2.2 |
1.183 |
|
|
2.5 |
1.326 |
|
|
2.8 |
1.464 |
|
|
3.0 |
1.554 |
|
|
3.2 |
1.641 |
|
|
3.5 |
1.769 |
|
|
4.0 |
1.973 |
|
|
25 |
2.2 |
1.237 |
|
2.5 |
1.387 |
|
|
2.8 |
1.533 |
|
|
3.0 |
1.628 |
|
|
3.2 |
1.720 |
|
|
3.5 |
1.856 |
|
|
4.0 |
2.072 |
|
|
26 |
2.2 |
1.291 |
|
2.5 |
1.449 |
|
|
2.8 |
1.602 |
|
|
3.0 |
1.702 |
|
|
3.2 |
1.799 |
|
|
3.5 |
1.942 |
|
|
4.0 |
2.170 |
|
|
27 |
2.2 |
1.346 |
|
2.5 |
1.511 |
|
|
2.8 |
1.671 |
|
|
|
3.0 |
1.776 |
|
3.2 |
1.878 |
|
|
3.5 |
2.028 |
|
|
4.0 |
2.269 |
|
|
4.5 |
2.497 |
|
|
28 |
2.5 |
1.572 |
|
2.8 |
1.740 |
|
|
3.0 |
1.850 |
|
|
3.2 |
1.957 |
|
|
3.5 |
2.115 |
|
|
4.0 |
2.368 |
|
|
4.5 |
2.608 |
|
|
30 |
2.5 |
1.695 |
|
2.8 |
1.878 |
|
|
3.0 |
1.998 |
|
|
3.2 |
2.115 |
|
|
3.5 |
2.287 |
|
|
4.0 |
2.565 |
|
|
4.5 |
2.830 |
|
|
5.0 |
3.083 |
|
|
32 |
2.8 |
2.016 |
|
3.0 |
2.146 |
|
|
3.2 |
2.273 |
|
|
3.5 |
2.460 |
|
|
4.0 |
2.762 |
|
|
4.5 |
3.052 |
|
|
5.0 |
3.329 |
|
|
34 |
2.8 |
2.154 |
|
3.0 |
2.294 |
|
|
3.2 |
2.431 |
|
|
3.5 |
2.633 |
|
|
4.0 |
2.959 |
|
|
4.5 |
3.274 |
|
|
5.0 |
3.576 |
|
|
5.5 |
3.866 |
|
|
35 |
3.0 |
2.368 |
|
3.2 |
2.510 |
|
|
3.5 |
2.719 |
|
|
4.0 |
3.058 |
|
|
4.5 |
3.385 |
|
|
5.0 |
3.699 |
|
|
5.5 |
4.001 |
|
|
38 |
3.2 |
2.746 |
|
3.5 |
2.978 |
|
|
4.0 |
3.354 |
|
|
4.5 |
3.718 |
|
|
5.0 |
4.069 |
|
|
5.0 |
4.408 |
|
|
6.0 |
4.735 |
|
|
40 |
3.2 |
2.904 |
|
3.5 |
3.151 |
|
|
4.0 |
3.551 |
|
|
4.5 |
3.940 |
|
|
5.0 |
4.316 |
|
|
5.5 |
4.680 |
|
|
6.0 |
5.031 |
|
|
6.5 |
5.370 |
|
|
42 |
3.5 |
3.323 |
|
4.0 |
3.749 |
|
|
4.5 |
4.162 |
|
|
5.0 |
4.562 |
|
|
5.0 |
4.951 |
|
|
6.0 |
5.327 |
|
|
6.5 |
5.691 |
|
|
7.0 |
6.042 |
|
|
45 |
4.0 |
4.044 |
|
4.5 |
4.495 |
|
|
5.0 |
4.932 |
|
|
5.5 |
5.358 |
|
|
6.0 |
5.771 |
|
|
6.5 |
6.172 |
|
|
7.0 |
6.560 |
|
|
7.5 |
6.936 |
|
|
48 |
4.0 |
4.340 |
|
4.5 |
4.827 |
|
|
5.0 |
5.302 |
|
|
5.5 |
5.765 |
|
|
6.0 |
6.215 |
|
|
|
6.5 |
6.652 |
|
7.0 |
7.078 |
|
|
7.5 |
7.491 |
|
|
8.0 |
7.892 |
|
|
50 |
4.5 |
5.049 |
|
5.0 |
5.549 |
|
|
5.5 |
6.036 |
|
|
6.0 |
6.511 |
|
|
6.5 |
6.973 |
|
|
7.0 |
7.423 |
|
|
7.5 |
7.861 |
|
|
8.0 |
8.286 |
|
|
51 |
4.5 |
5.160 |
|
5.0 |
5.672 |
|
|
5.5 |
6.172 |
|
|
6.0 |
6.659 |
|
|
6.5 |
7.133 |
|
|
7.0 |
7.596 |
|
|
7.5 |
8.046 |
|
|
8.0 |
8.484 |
|
|
8.5 |
8.909 |
|
|
53 |
4.5 |
5.382 |
|
5.0 |
5.919 |
|
|
5.5 |
6.443 |
|
|
6.0 |
6.955 |
|
|
6.5 |
7.454 |
|
|
7.0 |
7.941 |
|
|
7.5 |
8.416 |
|
|
8.0 |
8.878 |
|
|
8.5 |
9.328 |
|
|
54 |
4.5 |
5.493 |
|
5.0 |
6.042 |
|
|
5.5 |
6.578 |
|
|
6.0 |
7.103 |
|
|
6.5 |
7.614 |
|
|
7.0 |
8.114 |
|
|
7.5 |
8.601 |
|
|
8.0 |
9.075 |
|
|
8.5 |
9.538 |
|
|
9.0 |
9.988 |
|
|
56 |
4.5 |
5.715 |
|
5.0 |
6.289 |
|
|
5.5 |
6.850 |
|
|
|
6.0 |
7.398 |
|
6.5 |
7.935 |
|
|
7.0 |
8.459 |
|
|
7.5 |
8.971 |
|
|
8.0 |
9.470 |
|
|
8.5 |
9.957 |
|
|
9.0 |
10.432 |
|
|
57 |
5.0 |
6.412 |
|
5.5 |
6.985 |
|
|
6.0 |
7.546 |
|
|
6.5 |
8.095 |
|
|
7.0 |
8.632 |
|
|
7.5 |
9.156 |
|
|
8.0 |
9.667 |
|
|
8.5 |
10.167 |
|
|
9.0 |
10.654 |
|
|
9.5 |
11.129 |
|
|
60 |
5.0 |
6.782 |
|
5.5 |
7.392 |
|
|
6.0 |
7.990 |
|
|
6.5 |
8.576 |
|
|
7.0 |
9.149 |
|
|
7.5 |
9.710 |
|
|
8.0 |
10.259 |
|
|
8.5 |
10.796 |
|
|
9.0 |
11.320 |
|
|
9.5 |
11.831 |
|
|
63 |
5.5 |
7.799 |
|
6.0 |
8.434 |
|
|
6.5 |
9.057 |
|
|
7.0 |
9.667 |
|
|
7.5 |
10.265 |
|
|
8.0 |
10.851 |
|
|
8.5 |
11.424 |
|
|
9.0 |
11.985 |
|
|
9.5 |
12.534 |
|
|
65 |
5.5 |
8.070 |
|
6.0 |
8.730 |
|
|
6.5 |
9.378 |
|
|
7.0 |
10.013 |
|
|
7.5 |
10.635 |
|
|
8.0 |
11.246 |
|
|
8.5 |
11.844 |
|
|
|
9.0 |
12.429 |
|
9.5 |
13.003 |
|
|
10.0 |
13.564 |
|
|
68 |
5.5 |
8.477 |
|
6.0 |
9.174 |
|
|
6.5 |
9.858 |
|
|
7.0 |
10.530 |
|
|
7.5 |
11.190 |
|
|
8.0 |
11.838 |
|
|
8.5 |
12.473 |
|
|
9.0 |
13.095 |
|
|
9.5 |
13.706 |
|
|
10.0 |
14.304 |
|
|
11.0 |
15.463 |
|
|
70 |
6.0 |
9.470 |
|
6.5 |
10.179 |
|
|
7.0 |
10.876 |
|
|
7.5 |
11.560 |
|
|
8.0 |
12.232 |
|
|
8.5 |
12.892 |
|
|
9.0 |
13.539 |
|
|
9.5 |
14.174 |
|
|
10.0 |
14.797 |
|
|
11.0 |
16.005 |
|
|
73 |
6.0 |
9.914 |
|
6.5 |
10.660 |
|
|
7.0 |
11.394 |
|
|
7.5 |
12.115 |
|
|
8.0 |
12.824 |
|
|
8.5 |
13.521 |
|
|
9.0 |
14.205 |
|
|
9.5 |
14.877 |
|
|
10.0 |
15.537 |
|
|
11.0 |
16.819 |
|
|
12.0 |
18.052 |
|
|
75 |
6.5 |
10.981 |
|
7.0 |
11.739 |
|
|
7.5 |
12.485 |
|
|
8.0 |
13.219 |
|
|
8.5 |
13.940 |
|
|
9.0 |
14.649 |
|
|
9.5 |
15.346 |
|
|
10.0 |
16.030 |
|
|
|
11.0 |
17.362 |
|
12.0 |
18.644 |
|
|
76 |
6.5 |
11.141 |
|
7.0 |
11.912 |
|
|
7.5 |
12.670 |
|
|
8.0 |
13.416 |
|
|
8.5 |
14.150 |
|
|
9.0 |
14.871 |
|
|
9.5 |
15.580 |
|
|
10.0 |
16.277 |
|
|
11.0 |
17.633 |
|
|
12.0 |
18.940 |
|
|
80 |
7.0 |
12.602 |
|
7.5 |
13.410 |
|
|
8.0 |
14.205 |
|
|
8.5 |
14.988 |
|
|
9.0 |
15.759 |
|
|
9.5 |
16.517 |
|
|
10.0 |
17.263 |
|
|
11.0 |
18.718 |
|
|
12.0 |
20.124 |
|
|
83 |
7.0 |
13.120 |
|
7.5 |
13.965 |
|
|
8.0 |
14.797 |
|
|
8.5 |
15.617 |
|
|
9.0 |
16.425 |
|
|
9.5 |
17.220 |
|
|
10.0 |
18.003 |
|
|
11.0 |
19.532 |
|
|
12.0 |
21.012 |
|
|
85 |
7.0 |
13.465 |
|
7.5 |
14.334 |
|
|
8.0 |
15.191 |
|
|
8.5 |
16.036 |
|
|
9.0 |
16.868 |
|
|
9.5 |
17.688 |
|
|
10.0 |
18.496 |
|
|
11.0 |
20.074 |
|
|
12.0 |
21.603 |
|
|
89 |
7.5 |
15.074 |
|
8.0 |
15.981 |
|
|
8.5 |
16.875 |
|
|
9.0 |
17.756 |
|
|
|
9.5 |
18.626 |
|
10.0 |
19.483 |
|
|
11.0 |
21.160 |
|
|
12.0 |
22.787 |
|
|
90 |
7.5 |
15.259 |
|
8.0 |
16.178 |
|
|
8.5 |
17.084 |
|
|
9.0 |
17.978 |
|
|
9.5 |
18.860 |
|
|
10.0 |
19.729 |
|
|
11.0 |
21.431 |
|
|
12.0 |
23.083 |
|
|
95 |
8.5 |
18.132 |
|
9.0 |
19.088 |
|
|
9.5 |
20.031 |
|
|
10.0 |
20.962 |
|
|
11.0 |
22.787 |
|
|
12.0 |
24.563 |
|
|
100 |
8.5 |
19.180 |
|
9.0 |
20.198 |
|
|
9.5 |
21.203 |
|
|
10.0 |
22.195 |
|
|
11.0 |
24.144 |
|
|
12.0 |
26.043 |
|
|
14.0 |
29.692 |
|
|
16.0 |
33.145 |
|
|
18.0 |
36.400 |
|
|
102 |
8.5 |
19.600 |
|
9.0 |
20.642 |
|
|
9.5 |
21.671 |
|
|
10.0 |
22.689 |
|
|
11.0 |
24.686 |
|
|
12.0 |
26.634 |
|
|
14.0 |
30.383 |
|
|
16.0 |
33.934 |
|
|
|
18.0 |
37.288 |
|
108 |
9.0 |
21.973 |
|
9.5 |
23.077 |
|
|
10.0 |
24.168 |
|
|
11.0 |
26.314 |
|
|
12.0 |
28.410 |
|
|
14.0 |
32.455 |
|
|
16.0 |
36.302 |
|
|
|
18.0 |
39.952 |
|
110 |
9.0 |
22.417 |
|
9.5 |
23.546 |
|
|
10.0 |
24.662 |
|
|
11.0 |
26.856 |
|
|
12.0 |
29.002 |
|
|
14.0 |
33.145 |
|
|
16.0 |
37.091 |
|
|
18.0 |
40.839 |
|
|
120 |
10.0 |
27.128 |
|
11.0 |
29.569 |
|
|
12.0 |
31.961 |
|
|
14.0 |
36.598 |
|
|
16.0 |
41.037 |
|
|
18.0 |
45.279 |
|
|
130 |
10.0 |
29.594 |
|
11.0 |
32.282 |
|
|
12.0 |
34.921 |
|
|
14.0 |
40.050 |
|
|
16.0 |
44.983 |
|
|
18.0 |
49.718 |
|
|
20.0 |
54.255 |
|
|
140 |
12.0 |
37.880 |
|
14.0 |
43.503 |
|
|
16.0 |
48.928 |
|
|
18.0 |
54.157 |
|
|
20.0 |
59.188 |
|
|
150 |
14.0 |
46.956 |
|
16.0 |
52.874 |
|
|
18.0 |
58.596 |
|
|
20.0 |
64.120 |
|
|
22.0 |
69.447 |
|
|
160 |
14.0 |
50.408 |
|
16.0 |
56.820 |
|
|
18.0 |
63.035 |
|
|
20.0 |
69.052 |
|
|
22.0 |
74.872 |
|
|
170 |
14.0 |
53.861 |
|
16.0 |
60.766 |
|
|
18.0 |
67.474 |
|
|
20.0 |
73.985 |
|
|
22.0 |
80.298 |
|
|
24.0 |
86.414 |
|
|
180 |
18.0 |
71.913 |
|
20.0 |
78.917 |
|
|
22.0 |
85.723 |
|
|
24.0 |
92.333 |
|
|
190 |
18.0 |
76.352 |
|
20.0 |
83.849 |
|
|
22.0 |
91.149 |
|
|
24.0 |
98.251 |
|
|
200 |
20.0 |
88.781 |
|
22.0 |
96.574 |
|
|
24.0 |
104.170 |
|
|
210 |
20.0 |
93.714 |
|
22.0 |
102.000 |
|
|
24.0 |
110.089 |
|
|
220 |
20.0 |
98.646 |
|
22.0 |
107.426 |
|
|
24.0 |
116.008 |
|
|
240 |
20.0 |
108.511 |
|
22.0 |
118.277 |
|
|
24.0 |
127.845 |
|
|
250 |
22.0 |
123.702 |
|
24.0 |
133.764 |
